LAEB-A SERIES
Halogen lamp/HBM sensor
Aluminum shell/Stainless steel chamber
LCD(White back light with black font)
Temperature/Time set
The percentage of moisture content/dry residual
Store historical set
Option:Aluminum box/Printer/Grinder
| LAEB-A、LAEB-A-A specifications | |||||
| Model | LAEB-A100 | LAEB-A101 | LAEB-A102 | LAEB-A103 | LAEB-A103-A |
| Capacity | 110g | ||||
| Readability | 0.01g | 0.005g | 0.002g | 0.001g | |
| Operating Temp | 5℃-35℃ | ||||
| Display | LCD(White back light with black font) | LCD HD Back Display | |||
| Calibration | External Calibration | ||||
| Interface | RS232/RJ45/USB... | ||||
| Pan Size | Ø90mm | ||||
| Packing Size | 490x350x360mm | ||||
| Gross Weight | 7.5kg | ||||
| Heating Source | Halogen Lamp-1 | Halogen Lamp-2 | |||
| Temp.Sensor | PT100 | ||||
| Temp.Range | 40℃-199℃ | ||||
| Temp.Step | 1℃ | ||||
| Moisture Range | 0.00%-100.00% | ||||
| Moisture Readability | 0.2% | 0.10% | 0.04% | 0.01% | |
| Dry Range | 100.00%-0.00% | ||||
| Dry Readability | 0.2% | 0.10% | 0.04% | 0.01% | |
| Temp Setting | 40℃-199℃ By 1℃ Step | ||||
| Time Setting | 1-99min By 10s | ||||
| Number Of Storage | 15 | ||||
| Heater | 220V ±15% 50HZ/110V±15% 60HZ/400W | ||||
| Balance | Input:220V 50HZ/110V 60HZ Output:9V | ||||
