| Functions and features | |
White balance | Balances the color temperature in your image. |
HbE enhancement | Highlights the mucosal capillary morphology. |
Structure enhancement | Highlights the structure of endoscopic images. |
IRIS | Average;Peak |
Storage | USB |
Color adjustment | Adjustment of R,B,Y:± 50 |
Image enhancement | Manual |
Freeze and playback | Freezes a real-time image and plays it back |
| VME-92S/98S/1300S/1650S | ||||||||
Model | Working length | Diameter of distal end | Diameter of insertion tube | Diameter of instrument channel | Depth | View of field | Range of bending | |
Video Gastroscopes | VME-92S | 1050mm | 9.0mm | 9.0mm | 2.8mm | 3-100mm | 140° | U210°D90°L100°R100° |
VME-98S | 1050mm | 9.6mm | 9.6mm | 2.8mm | 3-100mm | 140° | U210°D90°L100°R100° | |
Video Colonscopes | VME-1300S | 1300mm | 12.8mm | 12.8mm | 3.7mm | 3-100mm | 140° | U180°D180°L160°R160° |
VME-1650S | 1650mm | 12.8mm | 12.8mm | 3.7mm | 3-100mm | 140° | U180°D180°L160°R160° | |
| VRL | ||||||||
Model | Working Length | Diameter of distal end | Diameter of insertion tube | Diameter of instrument channel | Depth | View of field | Range of bending | |
Video Laryngoscopes | VRL-Q30 VRL-1T30 | 450mm 450mm | 4.9mm 5.8mm | 4.9mm 5.7mm | 2.0mm 2.0mm | 2-50mm 2-50mm | 120° 120° | U130°D130° U130°D130° |
