Function
5 inch touch screen
Real time testing curve
Standard/Fast/Soft Mode
Automatic/Manual/Timed stop mode
Silent fast cooling fan
Adaptive input voltage
Test frequency selection
Clock function
Historical test report
Product specifications
LAEB-D SERIES |
Name | D100 | D101 | D102 |
Model | LAEB-D100 | LAEB-D101 | LAEB-D102 |
Capacity | 110 g | 110 g | 110 g |
Readability | 0.01 g | 0.005 g | 0.001 g |
Sensor | Load Cell | HBM |
Pan Size | Φ96mm（20pcs） |
Display | 5 inch touch screen |
Operate.Temp | 5℃-35℃ |
Heating Source | Halogen lamp |
Temp.Sensor | PT-100-2 |
Temp.Range | 40℃-160℃ |
Temp.Setting | 1℃ |
Moisture.Range | 90.00%-10.00% | 95.00%-5.00% | 100.00%-0.00% |
Moisture Readability | 0.1% | 0.05% | 0.01% |
Testing Range | 90.00%-10.00% | 95.00%-5.00% | 100.00%-0.00% |
DRY% Readability | 0.1% | 0.05% | 0.01% |
Storage | 20 Groups |
Analysis Curve | Real time dynamic curve |
Testing Height | 30mm |
LANGUAGE | EN/CN |
Power supplier | 220V 50Hz / 110V 60Hz |
Dimension | 336X214X166mm |
Packing Size | 415*310*255mm |
G.Weight/N.Weight | 4.0kg/3.5kg |
