Application
Simple YES/NO prompted operation.
High accurate and long life electrode and TCO,sensor.
Sleep mode to reduce reagent consumption.
Rapid test speed of 80 tests per hour.
Minimum sample volume is 60ul.
Individual reagent to avoid waste.
Optional:Sample tray.
Features
Automatic electric potential tracking and correcting software to ensure the stable performance.
Automatically detect and filter tiny bubbles to avoid clog and ensure accurate measurement.
Real-time diagnostic of system working status.Waste liquid automatic detection and alarming.
Automatic calibration and two-point correction to adjust slope and intercept.
Wave theory flushing method and direct flushing pipe method to avoid block and crossed contamination.
Power failure protection to avoid data losing,data storage could be extended to more than 20,000.
Available to power off any time,therefore reduce reagent consumption,suitable for any hospitals.
Parameter Configuration
Model | Test Project |
A | K,Na,Cl |
B | K,Na,Cl,TCO2,AG |
C | K,Na,Cl,iCa,nCa,TCa,pH |
D | K,Na,Cl,iCa,nCa,TCa,pH,TCO2,AG |
F | K,Na,Cl,Li |
H | K,Na,Cl,iCa,nCa,TCa,pH,Li |
I | K,Na,Cl,iCa,nCa,TCa,pH,Li,TCO2,AG |
J | K,Na,Cl,Li,Mg |
K | K,Na,Cl,iCa,nCa,TCa,pH,Mg |
L | K,Na,Cl,iCa,nCa,TCa,pH,Mg,TCO2,AG |
M | K,Na,Cl,iCa,nCa,TCa,pH,Li,Mg,TCO2,AG |
Analysis Method: lon selective electrode(ISE) Sample Volume: 60-300ul (item 3 to item 11) Sample Position: 35 positions(including 1 QC) Storage: Up to 10000 test results Printer: Internal thermal printer Interface: RS232 port | Working Environment: Temperature: 5~40C Relative Humidity: s 80% Atmospheric Pressure: (86~106)kPa Power Supply: AC110/220V±10%，60/50Hz Power: ≤120 |
Item | Measuring Range | Resolution | Measuring Precision(CV%) |
K+ | 0.5~20.0mmol/L | 0.01 mmol/L | ≤1.0% |
Na+ | 15~200mmol/L | 0.1 mmol/L | ≤1.0% |
Cl- | 15~200mmol/L | 0.1 mmol/L | ≤1.0% |
Ca2+ | 0.1~6.0mmol/L | 0.01 mmol/L | ≤1.0% |
Li+ | 0.1~5.0mmol/L | 0.01 mmol/L | ≤2.0% |
pH | 4~9pH | 0.01 pH | ≤0.5% |
TCO2 | 2.0~70.0mmol/L | 0.1 mmol/L | ≤3.0% |
