Features:
• 12.1”TFT touch screen (optional 15.6”)
• User friendly interface.
• Tidal volume 10-1500 ml, optional choice 5~1500 ml
• Semi-electronic flowmeter.
• PPSU/Metallic material breathing circuit.
• By-pass Tech for soda lime canister.
• All ventilation modes to satisfy neonate, pediatric and adult patients.
• Integrated breathing circuit with built-in heater.
• High visible ACGO.
• Optional plug-in module socket.
Exellent CO2 absorber
One-hand operation designed CO2 absorber
By-pass design ensures the safety of replacing soda lime
Canister during the operation
Canister on-line detector
Autoclavable PPSU material (up to 134°C)
Large workbench
Two-sided guide rails (optional) for patientmonitor, support arm and injection bump.
Stainless steel material can stand anychemical sterilization agent
LED lights equipped to provide lighting forthe workbench.
