LSF-2 Electric Suction Apparatus

Product overview

1. Maintenance free, oil-less pump, and high flow rate with less po-llution.

2. Large-diameter storage bottle, stopper with sealing ring, easy toopen, fasten down and clean.

3. Overflow protection devioe prevents liquid from entering into theinner pipe and pump.

4. Transparent non-toxic PVC hoses, easy for observation.5. Air filter protects pump from being polluted.6. Hand switch and foot switch installed in parallel, can be selectedat will

7. Work stably and durably, low noise, long service life.

Specification parameter

1. Max Vacuum: >0.09MPa (680mmHg)

2. Adjustable vacuum range:0.02~0.09MPa(150~680mmHg)

3. Flow rate: >40L/min

4. Noise: ≤60dB (A)

5. Storage bottles: 2500mlx2(glass) (the two or one of themcan be changed to 2L or 3L PC bottle)

6. Input: 250VA

7. Power supply: AC220V 50Hz

8.Dimension: 320mmx360mmx830mm

9. Package Dimension: 465mmx425mmx935mm

10. G.W./N.W.: 22.5 kg/20kg
